Handheld Fiber Laser Cleaning Machine for Rust Removal
TochTech handheld laser cleaning machine is an eco-friendly cleaning solution that quickly and precisely removes contaminants from various surfaces without physical contact. -Quickly removes contaminants like oil, rust, and coatings from various materials while protecting surfaces. -Operates without chemicals, minimizing pollution and reducing energy consumption. -Offers controlled, selective cleaning ideal for diverse industrial applications.
Description
This Handheld Laser Cleaning Machine for Rust effectively eliminates resin, oil, dirt, rust, coatings, plating, and paint from workpiece surfaces. The laser rust removal machine meets the demands for cleaning intricate shapes and precise positioning in industrial applications, resulting in superior cleanliness. Despite its higher initial costs, it addresses low production efficiency. This technology is primarily utilized in sectors such as automotive manufacturing, mechanical processing, electronics, cultural heritage restoration, mold production, shipbuilding, food processing, and petrochemicals.
Technical Specifications
|
Product model |
TC-H1000 |
TC-H1500 |
TC-H2000 |
TC-H3000 |
|
Rated output power |
1000W |
1500W |
2000W |
3000W |
|
Maximum output power |
1000W |
1500W |
2000W |
3000W |
|
Laser wavelength |
1080nm |
|||
|
Maximum modulation frequency |
20KHZ |
|||
|
Fiber diameter |
50um/100um Optional |
|||
|
Output fiber length |
10m,15m,20m(optional) |
|||
|
Weld depth |
0.1-2mm |
0.1-3.5mm |
6mm |
|
|
Electricity demand |
AC220V/380V,50/60HZ,three-phase |
|||
|
Aiming and fixing |
Red light |
|||
|
Cooling mode |
water-cooling |
|||
|
Operating ambient temperature |
10-350℃ |
|||
|
Carton size |
Length 1330mm,width 620mm,height 800mm |
|||
Applications
1.Rust and Contaminant Removal: Effectively eliminates rust, oil, and other contaminants from metal surfaces, making it ideal for automotive and manufacturing maintenance.
2.Paint and Coating Removal: Strips paint and coatings for surface preparation without harming the underlying metal.
3.Metal Welding: Offers precision welding for small-scale repairs and assembly in automotive, electronics, and jewelry industries.
4.On-Site Maintenance and Repair: Its compact design makes it perfect for field maintenance, especially for pipes, structural parts, and small components.
Metal rust removal
laser cleaning the oxide layer
Remove paint
Tire cleaning
Metal laser welding
Thick metal laser cutting
main parts
Fast Speed digital laser cleaning head
It adopts a handheld design, which is comfortable to hold and can flexibly respond to various objects and angles. Easy to operate and portable to move.
The intelligent cleaning welding gun with temperature monitoring can monitor the protective lens and give early warning of damage. It is easy to use, flexible in processing, small in size, easy to carry, and low in operation and maintenance costs.
请替换当前内容 This 50kVA single phase pole mounted transformer is exported to Canada inJuly,2024.The rated power of the pole mounted transformer is 50 KVA, the primary voltage is 34.5 kV and secondary voltage is 0.48v/0.277 KV. Western developed countries and Southeast Asia. North and South America, a large number of single-phase pole mounted This 50kVA single phase pole mounted transformer is exported to Canada inJuly,2024.The rated power of the pole mounted transformer is 50 KVA, the is 50 KVA, the is 50 KVA, the is 50 KVA, the is 50 KVA, the is 50 KVA, the is 50 KVA.
Raycus or MAX Laser Generator
MAX has an efficient and professional R&D and production team, which is the top quality in China.
The lasers have higher electro-optical conversion efficiency, higher and more stable optical quality. Low error rate, low power consumption, maintenance-free and compact.
Controller
Laser welding machine support a variety of different swing types, automatic wire feeding and other functions.
The system is easy to operate and can display real-time input and output IO status, alarm information and motion status.
The process parameter library is stored in the laser cleaning and welding machine. Each mode corresponds to different parameter settings. After saving, you can directly select the corresponding mode next time without setting the parameters again.
S&A Water Chiller
Specially developed for fiber laser equipment, excellent cooling effect. It has safe, durable, and stable working performance with long service life.
The built-in chiller design can avoid the shackles of wires to fit more sites and has good dustproof effects. A powerful and stable water cooling system will ensure the perfect working of the fiber laser source.
