MAX 1000W 1500W CW Fiber Laser Source
The fiber laser source is specially designed for industrial laser making system and other applications.Compared with traditional lasers, the fiber laser source is exquisite and convenient for its independence in placement, free time in using and facility in connecting toequipment directly.
Description
Products overview
MAX 1500w Fiber Laser Source is specially designed for industrial laser welding system and other applications. Compared with traditional lasers, the fiber laser source is exquisite and convenient for its independence in placement, free time in using and facility in connecting toequipment directly.
Products features
max photonics laser source
1. Premium components,superior performance and longer lifetime Up to 6KW Output From Max CW Single Module Series
2. Excellent Material Processing Performance：High speed in thin sheet cutting;Strong capability in thick material processing
3. Compact Design,Maintenance Free：Highly integrated system with modular design;Easy maintenance significantly reduce TCO
4. Smaller Size with Higher Stability：>60% reduction in volume;Higher flexibility when integrated in to system
5. High Level Vertical Integration：All key components are designed and produced in house; Strict quality control,high consistency and reliability
Products Details
max laser source 1.5kw front Side
1.Emergency stop: Emergency stop switch
2.OFF/ON: Laser source switch
3.Start: External laser start button
4.Power: Laser power indicator
5.Active: Laser normal status indicator lamp
6.Alarm: Laser abnormal status alarm indicator
max laser source 1.5kw back side
1.Optical Output: Laser output port
2.Power: Leakage protector
3.Power connection: Laser power input line
4.CTRL: Laser external control interface
5.RS232: RS232 interface
6.Water out: Laser water-cooled outlet
7.Water in: Laser water-cooled inlet
Products Specifications
Parameter comparison between MAX 1000W lasers and MAX 1500W lasers
| Models | MFSC-1000W | MF5C-1500W |
| OPTICAL SPECIFICATIONS | ||
| Nominal Power | 1000W | 1500W |
| Polarization | Random | |
| Power Tuna bility | 10 to 100% | |
| Wavelength | 1080 ± 10 nm | |
| Power Stability | ±1 % | |
| Beam Quality M² |
1.3(20u-QBH Output) 2.8(50u-QBH Output) |
|
| Modulation Frequency | 20kHz | |
| Preview Red Light Power | 150 pW | |
| FIBER DELIVERY SYSTEM | ||
| Interface | QBH(LOC) | |
| Length | 15m standard, other lengths optional | |
| Diameter | 50 pm | |
| Bending Radius | 200 mm | |
| ELECTRICAL RATINGS | ||
| Supply Voltage | 220VAC (-15% to +10%) Single-phase | |
| OTHER SPECIFICATIONS | ||
| Operating Temperature | +10 to +40-C | |
| Storage Temperature | -10 to +60'C | |
| Humidity | 10 to 85% | |
| Cooling Method | Water Cooling | |
| Cooling Medium | Distilled water/ Glycol Antifreeze | |
| Dimension | 482.6x800x193mm(WxDxH) | |
| Weight | 53(±3)kg | I 57( ± 3) kg |
Products Application
The function of the handheld laser welding head is to directly transfer laser energy to the workpiece, causing its surface to melt rapidly and form a molten pool through fast heat conduction. The advantages of laser welding include high speed, precision, a small heat-affected zone, deep penetration, rapid cooling, and high joint quality. The handheld laser welding head also offers flexible operation, making it suitable for use in narrow workspaces and for welding complex parts and shapes.
Products Package
The packaging of our lasers provides robust protection during transportation and storage, shielding the laser machine from physical damage such as collisions or drops. Its thickness also safeguards the device from environmental factors like moisture, heat, and dust, ensuring that the MAX Laser arrives at the customer's location in optimal condition.*
