Enclosed Laser Marking Machine with Turn Table
The Enclosed Laser Marking Machine with Turn Table is a laser marking system designed with a fully enclosed structure for operator safety and a rotating turntable for continuous marking. The turntable allows for multiple stations to load, mark, and unload parts simultaneously, which enhances workflow and productivity.
Description
Enclosed Laser Marking Machine With Turn Table Introduction
The Enclosed Laser Marking Machine with Turn Table is a laser marking system designed with a fully enclosed structure for operator safety and a rotating turntable for continuous marking.
The turntable allows for multiple stations to load, mark, and unload parts simultaneously, which enhances workflow and productivity.
The Enclosed Laser Marking Machine with Turn Table is an advanced laser marking system designed for high-speed, precise, and continuous marking operations.
Featuring a rotating turntable design within a fully enclosed structure, it ensures efficiency and operator safety.
This machine is ideal for industries requiring high-volume production and detailed marking on various materials.
The rotating turntable enhances productivity, while the enclosed design ensures operator safety and environmental compliance. Whether marking flat, curved, or complex surfaces, the Enclosed Laser Marking Machine with Turn Table offers reliability, quality, and unmatched performance for diverse applications.
We can also customize the machines according to the specific needs from customers.
Please freely to contact us for more details
What is the difference between 2D 2.5D 3D machines?
2D laser with 2D galvo scanning head and EZCAD2 control card, EZCAD2.1 4.11 version software.
It can mark flat metal and some nonmetal surface , deep engraving metal and cutting some thin metals.
2.5D laser means 2D laser + motorized Z axis + EZCAD3 software.
Based on the common 2D laser, the latest 2.5D machine is composed by the motorized Z axis and EZCAD3 software, mainly used for STL file metal mold coin relief engraving etc + All features of 2D machines.
3D laser is the most comprehensive machine, which also have the motorized Z axis and EZCAD3 control card, plus a 3D Dynamic focus scanning head , it can be used for curved surface (app 120 degree) marking without rotary, can be used for metal mold and coin relief engraving, what's more, it can be used for big format like 300*300mm metal deep engraving. (for 2D and 2.5D laser, the max deep engraving area is app 110*110MM)
Enclosed Laser Marking Machine With Turn Table Functions
2D and 3D laser for option marking / printing / engraving machine work on all metal material and some plastic material.
It has 2D, 2.5D, 3D marking, Relief and cutting 5 functions.
This 3D fiber laser marking machine is suitable for marking custom logo, text, symbol, pattern,
barcode, 2D code, serial number, etc.
This machine can mark a wide variety of parts, including:
Automotive parts (engine components, tools, etc.)
Electronics (PCB boards, connectors, microchips, etc.)
Medical devices (surgical instruments, implants, etc.)
Jewelry (rings, necklaces, watches, etc.)
Packaging materials (bottles, cans, cartons, etc.)
Enclosed Laser Marking Machine With Turn Table Main Features
1. Rotating Turntable for Continuous Workflow
Equipped with a multi-station turntable that rotates to enable simultaneous loading, marking, and unloading.
Significantly reduces idle time and increases productivity.
Allows for continuous marking cycles, ideal for mass production.
2. Fully Enclosed Design
Provides a safe working environment, shielding operators from laser radiation and debris.
Reduces noise and contains dust and fumes with an integrated extraction system, ensuring a clean and eco-friendly workspace.
3. High-Performance Laser Source
Uses fiber laser technology for fast, precise, and permanent marking.
Delivers high beam quality and detailed engraving with excellent repeatability.
4. Customizable Turntable and Marking Area
Turntable sizes and configurations can be tailored to fit specific production needs.
Marking areas range from 110 mm x 110 mm to 300 mm x 300 mm, depending on the lens selection and application.
5. Advanced Control Software
Powered by EZCAD or equivalent software, offering intuitive control and design capabilities.
Supports a wide range of file formats, such as DXF, PLT, AI, BMP, and JPG.
Features real-time preview for accurate alignment and configuration.
6. 3D Auto-Focus Capability
Automatically adjusts the laser focus to accommodate varying surface heights and complex geometries.
Ensures consistent marking quality on flat, curved, or irregular surfaces.
Main Parts
Fiber Laser source.
Original Raycus/JPT/ IPG/Max optional.
Stable working lifetime up to 100,000+ hours.
JCZ 3D digital galvanometer
scanning head. Not only can do 2D marking function, but also can do 3D deep engraving and relief.
2D scanning head is also optional.
F-theta lens
Best brand "Wavelength"
Working area 50*50mm-300*300mm optional
Beijing JCZEZCAD2 control card
Genuine EzCAD control system compatible with windows system.
User-friendly interface and high stability.
Easy operation.
1/2 Turn-table.
Two station marking.
Can be continuous marking,
improvework efficiency.
Speed Controller
High
Low
RUN
Speed control for rotatetable.
Low and high adjustable.
Standard 68cmheight
Alsohave800mmforoption.
The"UP"and"DOWN"
buttons to adjust the focus
distance height.
The safety barriers
For protective function.
Ifoperator approaches
the marking area, then
ecH
826161892
machine will stop
working immediately.
Control buttons
Emergency stop:Press it when meets errors,the machine will stop working immediately.
Key switch:Using key switch to control the power of the machine.
JCZEZCAD3 for 3D laser.
Compatible with multiple formats and vector file formats, simple operation.
Many different languages offered.
Enclosed Fiber Laser Marking Machine Parameters
| Laser Power | 30W/50W/60W/100W/120W/200W Optional |
| Laser Source | Raycus/Max/IPG/JPT MOPA |
| Control Board | BJJCZ |
| Control Software | EZCAD |
| Galvo Head | Sino-Galvo |
| F-theta Lens | 100mm-400mm Optional |
| Laser Lifespan | 100,000 Hours |
| Laser Wavelength | 1064nm |
| Marking Speed | 0-8000mm/s |
| Power Consumption | 800W |
| Cooling Mode | Cooling Mode |
| Supported characters | Any fonts downloaded on computer |
| Supported format | DWG,DFX,BMP JPG PNG,TIF. PCX, TAG, GIF, PLT etc |
| Supported Bar code | CODE39, EAN, CODE128, Data Matrix, PDF417 etc. |
| Voltage | 110V/220V Optional |
Samples
Packing & Shipping
FAQ
1. How does the rotating turntable work?
The rotating turntable allows for the automated movement of parts between multiple positions:
Loading position: Parts are placed on the turntable.
Marking position: The laser head marks the parts.
Unloading position: Marked parts are removed, while new parts are loaded for marking.
This design reduces idle time and allows for continuous production.
2. What materials can be marked with this machine?
The Enclosed Laser Marking Machine with Turn Table is suitable for a wide range of materials, including:
Metals: Stainless steel, aluminum, copper, titanium, brass, etc.
Plastics: ABS, PVC, polycarbonate, etc.
Non-metals: Ceramics, glass, coated surfaces, and more.
3. Can the turntable be customized?
Yes, the turntable design can be customized to meet specific production requirements. The size, number of stations, and rotation speed can be adjusted based on the size of the parts being marked and the required production speed.
4. Can this machine be integrated into an automated production line?
Yes, the Enclosed Laser Marking Machine with Turn Table is highly suitable for integration into automated production lines. It can be connected to conveyor systems, robotic arms, or other automation equipment to streamline the production process and increase throughput.
5. What are the main benefits of the enclosed design?
Operator Safety: The machine's enclosed structure ensures operators are protected from laser exposure and harmful fumes.
Environmental Control: The enclosure helps to contain dust, debris, and fumes, creating a cleaner, safer work environment.
Noise Reduction: The enclosed housing reduces noise levels, contributing to a quieter, more comfortable workplace.
Could you let us know more about your request? So we can recommend the best solutions for you:
1. What kind of materials of your workpiece? metal or non-metal?
2. What is the marking area/size needed?
3. Mark on flat surface or curved/round?
We can also customize the machines according to the specific needs from customers.
Please freely to contact us for more details
