Raycus 2000W CW Fiber Laser Source
Raycus Global Edltion CW Fiber laser employs latest high-per-formance optical fiber,which is developed by Raycus and highly matches Raycus technical solutions.The optical fiber can withstand high output power while has good control of beam quality.It has enhanced ability to reduce photodarken-ing while lowering the rate of power attenuation effectively.New coating material and longer time of burning-in test is applied to the optical fiber.The Global Edition CW Fiber laser adopts new generation laser chips,which feature high power,high brightness and long service life.All the lasers of this series comply with CE standard.
Description
Products overview
Raycus Global Edltion CW Fiber laser employs latest high-per-formance optical fiber,which is developed by Raycus and highly matches Raycus technical solutions.The optical fiber can withstand high output power while has good control of beam quality.It has enhanced ability to reduce photodarken-ing while lowering the rate of power attenuation effectively.New coating material and longer time of burning-in test is applied to the optical fiber.The Global Edition CW Fiber laser adopts new generation laser chips,which feature high power,high brightness and long service life.All the lasers of this series comply with CE standard.
The new generation of Cw lasers has the advantages of high electro-optical conversion efficiency,good beam quality,high energy density,wide modulation frequency,high reliability and maintenance-free operation.In the application of metal cutting.this series of lasers can achieve more stable and precise cutting effect.
Typical Applications
Precislon Cutting
Metal Welding
Sheet Metal Piercing
Metal Carving
Surface Treatment
Metal Cutting
Products Characteristics
High Electro-optical Conversion Efficiency
Resistance To High Reflection
High Beam Quality
High Safety Performance
Sheet Cutting Efficiency
Maintenance-free Operation
Products specifications
| Model Average Output Power (W) |
RFL-C1000S-CE 1000 |
RFL-C1500S-CE Optical 1500 |
RFL-C2000S-CE Properties 2000 |
RFL-C3000S-CE 3000 |
RFL-C40005-CE 4000 |
I | |
| Central Wavelength (nm) |
1080±5 | ||||||
| Operation Mode | CW/Modulate | ||||||
| Modulation Frequency (Hz) |
1-5000 | 1-20000 | |||||
| Output Power Instability |
± 1.5% | ||||||
| Red Guide LaserPower (mW) Terminal Type |
05-1 Output Characteristics QBH (Customizable) |
1-1.5 | |||||
| IQB (Customizable) |
QBH (Customizable) | ||||||
| Beam Quatity(BBP) | <1.5 | 1.5-2 (50pm) | L7-2.5 (50pm) | 2.7-3.1 (75pm) | |||
| Core Fiber(pm) | 25 Customizable) |
50 (Customizable) | 50(75'1001200) | 75(50 \ 100 \ 2 options | |||
| Polarization State | Random | ||||||
| Delivery Cable Length(m) Power Supply |
20 (Customizable) Electrical Characteristics 220± 10% V AC,50/60Hz Three Phase four Wire Connect 380 -±10% VAC |
||||||
| Control Mode | RS232/AD/Ethernet | ||||||
| Power range(%) Dimensions (mm) WXHXD |
10-100 | ||||||
| Other Characteristics 440 x586x149 | 485X172X727 | 485 x172 x 802 | |||||
| Weight(kg) | <25 <28 | '55 | <80 <80 | ||||
| Water Cooling | |||||||
| Cooling | |||||||
| Operating Temperature ('C) |
10-40 | ||||||
